XRME210302017
XINDRAY
Product features
1. Professional design assures your convenient operation and accurate measurement.
2. Friendly man-machine conversation interface
3. Realtime reaction curve displayed, abnormity detected in time.
4. Particular reproducibility performance test, easy to know the instruments status
5. Multi-forms in result output including patient comprehensive report
Technical Specification:
| Model | XRME210302017 |
Reading Cuvette | Quartz flow through cell |
Measuring Volume | 450ul-800ul |
Incubator | 20 including positions |
Photometric System | Light Source: 6V/10W halogen lamp; Standby function |
Wavelength: 340/405/492/510/546/578/620nm, 2 more filters available on request | |
Wavelength Accuracy: ±2nm | |
Thermostatic Control | Temperature: 25℃, 30℃, 37℃ |
Precision: ±0.1℃ | |
Measuring System | Method: End point, Fixed time, Multi standard, Biochromatic and Immunoturbidimetry, etc. |
Photometric Linearity: ±2%(0~3.0000D) | |
Photometric Accuracy: ±1%(0~3.0000D) | |
Carry-over: <=1% | |
Drift | <0.005 0D/HR |
Display | Back-illuminated LCD |
Storage | Over 180 programs, 3000 test results |
Interface | RS-232 serial port, USB port |
Power Supply | AC 110V/60Hz or 220V/50Hz |
Dimension | 34cm*38cm*18cm |
Weight | 8kg |
