Infusion mode

Rate mode, Time mode, Body weight mode, Dose mode, Intermittent mode, TIVA, Program mode, TPN mode, Switch mode, Drug library

Applicable syringes

Various brands of sterile syringes: 2 ml, 5 ml, 1 0 ml，20 ml, 30 ml, 50 ml/60 ml, including BD.B.Braun, Terumo, Nipro etc.

Syringe accuracy

±2% (after syringe correct calibration)

Infusion rate

2 ml syringe: 0.1 - 150 ml/h
5 ml syringe: 0.1 - 150 ml/h
1 0 ml syringe: 0.1 - 300 ml/h . , ^
1 ^ , increment: 0.01 ml/h 20 ml syringe: 0.1 - 600 ml/h
30 ml syringe: 0.1 - 900 ml/h
50 ml syringe: 0.1 - 1800 ml/h

Volume to be infused

0〜9999.9 (ml) increment: 0.01 ml/h

Volume Infused

0-9999.9 (ml)

KVO rate

0~5 ml/h adjustable； default value： 0.1 ml/h

Bolus

Manual Bolus / Automatic Bolus:0.1 〜1800 ml/h (depend on syringe size)

Alarms

Infusion completion, Empty, Occlusion, Near completion, Low battery,
Syringe disengaged, No AC power supply, Battery exhausted, Malfunction etc

Functions

Standby function: 1 min - 24 hours adjustable
13 occlusion levels
History records more than 2000
Can change the flow rate and VTBI without stopping the infusion Compatible with hospital HIS system WIFI connect to central monitoring system

Power supply

DC:12±1.2V; AC: 100〜240V, 50/60 Hz

Power consumption

25 VA

Nurse call function

Optional

Classification

Class I, type CF

Dimensions

230 * 1 37 * 1 39 (Length x Width x Height)

Net Weight

1.7 KG

Waterproof Level

IP24

Battery

Li_polymer 7.4V 1 900Ah, more than 6 hours at 5ml/h

Operating conditions

Temperature: 5°C ~ 40°C, Relative humidity: 10 ~ 95%, Atmosphere pressure: 86~ 106kPa

Transport conditions

Temperature: -20°C〜60°C, Relative humidity: 10〜95%, Atmosphere pressure: 50 ~ 106 kPa

Storage conditions

Temperature: -20°C ~ 45 °C, Relative humidity: 10-95 %, Atmosphere pressure: 50 ~ 106kPa
