XRME220210368
XINDRAY
Feature:
1. Microprocessor based servo controlled temperature system.
2. The microprocessor-controlled unit allows for three settings: Pre-warm, manual or automatic.
3. Alarm functions for safety includes: Power failure, temperature deviation, Temperature sensor failure, over temperature.
4. APGAR timer to record therapy time
5. Convenient X-ray cassette under infant bed
6. Tilt angle of infant bed is adjustable from panel
7. Observe light angle is adjustable
8. Transparent protector folded
Specification:
| Technical data | |
| Power supply | Ac110/220v 60/50hz |
| Power input | 1100VA |
| Environment temperature | 18℃-30℃ |
| Environment relative humidity | 30%-75% |
| Atmospheric pressure | 700-1060hpa |
| Environment air velocity of flow | <0.3m/s |
| skin temperature control range | 32℃-38℃ |
| Skin temperature control accuracy | ≤0.5℃ |
| Skin temperature sensor accuracy | 土0.3℃ |
| Mattress temperature uniformity | <2℃ |
| Infant Bed tilt angle | ±12° |
| Warm-up time(from25℃) | <30min |
| LED observation light | 3W |
| Distance from heater to mattress | 80cm |
| Mattress size | 78cm X 64cm |
| Timer range | 0～99h59min |
| LED phototherapy light 36cm | 620-2800μw/c㎡ |
| LED phototherapy light 50cm | 400-1620μw/c㎡ |
| Oxygen cylinder | 6L X 2 |
| Oxygen flow meter | 0-10L/min |
