Multi-Functional Electric Operating Table

Multi-Functional Electric Operating Table

Produts feature

This operating table uses microcomputer to control electric hydraulic transmission system.It`s easy to use,safe and reliable.It can meet the surgery requirements for the general surgery department,heart renal,orthopedics,neurosurgery,gynecology and urology.

Main parts of the hydraulic system are imported to be more reliable and durable.

The tabletop framework is aluminum casting.The base and outer cover are made from 304 stainless steel, and they are high impact, wear-resisting, easy cleaning and maintenance conveniently.

Accessories:

Anesthesia screen frame, Shoulder supporter, Arm supporter, Body supporter, Leg supporter, Mattress

Parameters:

Overall length:2000mm

Width:500mm

Height:750mm

Lifting range:≥245mm

Tabletop lean forward angle≥22°

Tabletop lean backward angle≥25°

Tabletop lean left angle≥20°

Tabletop lean right angle≥20°

Back board folded up angle≥70°

Back board folded down angle≥70°

Head board folded up angle≥45°

Head board folded down angle≥90°

Waist board lifting height≥80mm

Leg board folded down angle≥90°

Leg board open angle≥90°

Lengthways sliding range≥295mm
