1.On-line HDF
2.Adopted closed volume balance chamber, accurate ultrafiltration dehydration control;One-key low speed ultrafiltration: can set low speed UF, low speed UF working time, return to normal UF speed automatically after execution; support isolated UF, can modify the executed time and UF volume based on requirement while isolated UF.
3. One-key dialyzer priming+ functionCan set priming time, priming dehydration volume which effective use of diffusion and convection mechanism to improve the priming effect of bloodlines and dialyzer and improve the dialysis adequacy
4. Intelligent automatic disinfection and cleaning procedure
Availability: | |
---|---|
XRME210210125
XINDRAY
Feature:
1.On-line HDF
2.Adopted closed volume balance chamber, accurate ultrafiltration dehydration control;One-key low speed ultrafiltration: can set low speed UF, low speed UF working time, return to normal UF speed automatically after execution; support isolated UF, can modify the executed time and UF volume based on requirement while isolated UF.
3. One-key dialyzer priming+ functionCan set priming time, priming dehydration volume which effective use of diffusion and convection mechanism to improve the priming effect of bloodlines and dialyzer and improve the dialysis adequacy
4. Intelligent automatic disinfection and cleaning procedure
5.It can effectively prevent the deposition of calcium and protein in the pipeline of the machine, unnecessary to use sodium hypochlorite to remove protein which avoids the injury to medical personnel during the use of sodium hypochlorite.
6.One-key drainage functionConvenient and practical one-key drainage function, automatically remove the waste liquid in the bloodline and dialyzer after dialysis treatment, which prevents waste liquid from spilling on the ground when dismantling the pipeline, effectively keep the treatment site clean and reduce the management and transportation cost of medical waste.
7.Intelligent Haemodialysis device alarm system
8.History record of alarm and disinfection
9.15 inches LCD touch screen
10.Kt/V evaluation
11. Customized the Sodium and UF profiling parameter setting based on patients’ actual treatment situation, which is convenient for clinical personalized treatment, patients will feel more comfortable during dialysis and reduce the incidence of common adverse reactions.
Technical Parameter | Size | 380mmx400x1380mm (L*W*H) |
Area | 500*520mm | |
Weight | 88KG | |
Power supply | Power supply | AC220V, 50Hz/60Hz, 10A |
Input power | 1500W | |
Back-up battery | 30 minutes | |
Working Condition | Water input pressure | 0.1Mpa~0.6Mpa, 15P.S.I~60P.S.I |
Water input temperature | 5℃~30℃ | |
Working environment temperature | 10℃~30℃ at relative humidity ≦70% | |
UF rate | Flow range | 0ml/h~4000ml/h |
Resolution ratio | 1ml | |
Precision | ±30ml/h | |
Blood pump & substitution pump | Blood pump flow range | 30ml/min~600ml/min (diameter: 8mm or 6mm) |
Substitution pump flow range | 30ml/min~600ml/min (diameter 8mm or 6mm) | |
Resolution ratio | 0.1ml | |
Precision | ±10ml or 10% of reading | |
Heparin pump | Syringe size | 20, 30, 50ml |
Flow range | 0ml/h~10ml/h | |
Resolution ratio | 0.1ml | |
Precision | ±5% | |
Storage Environment | Storage temperature should be between 5℃~40℃, at relative humidity ≦80% |
Air bubble monitor
Infrared and response threshold value | Single air bubble of 200u I exists when Blood flux is 200ml/min |
Inflow pressure | 0MPa~0.6MPa |
Inflow temperature | 5ºC~30ºC |
Environment temperature | 10ºC~30ºC, Relative humidity≤70% |
Rinse/disinfection | chemical disinfection (citric acid,peracetic acid and oxalic acid) |
Hot rinse | 80ºC |
Back-up power supply | last for 15-30min after electric-cut. |
Monitoring system & Alarm setup
Venous pressure | -180mmHg ~ +600mmHg, ±10mmHg |
Arterial pressure | -380mmHg ~ +400mmHg, ±10mmHg |
TMP | -180mmHg ~ +600mmHg, ±20mmHg |
Dialysate temperature | preset range 34.0℃~39.0℃ |
Dialysate flow | Less than 800 ml/min (Adjustable) |
Substitution flow range | 0-28 L/H (on line HDF) |
Blood leak detection | Photo chromic alarm when erythrocyte specific volume is 0.32±0.02 or blood leak volume is equal or more than 1ml per liter of dialysate. |
Bubble detection | Ultrasonic, Alarm when a single air bubble volume is more than 200μl at 200ml/min blood flow |
Conductivity | Acoustic-optic |
