1. Gas driven electronically controlled.
2. Time switch, volume control, pressure limit ventilation mode.
3. I:E function
4. LCD display ventilation parameters, preset parameters alarm indication and breathing waveform
5. Applied for adult and child
XRME220204433
XINDRAY
Feature:
1. Gas driven electronically controlled.
2. Time switch, volume control, pressure limit ventilation mode.
3. I:E function
4. LCD display ventilation parameters, preset parameters alarm indication and breathing waveform
5. Applied for adult and child
Specification:
| MODEL | XRME220204385 |
| Power Input | |
| 220Vは10％0），50Hz（t2％）or110v6OHz | s |
| Battery Back-up | |
| Internal Rechargeable | s |
| Sealed Lead Acid 12V | (<=2hours) |
| Screen Size( inch) | 5.7 |
| Gas | |
| 02 Air | 02 Air |
| Pipeline input Range | 280kpa-600kpa |
| Breathing Rate | 1-100/min |
| Inspiratory Duration | 0.2-6s |
| Tidal volume(V) | 50-1500ml |
| breath holding time | 0-50% |
| PEEP | |
| CPAP | |
| Ventilation Mode | |
| VCV | s |
| PCV | |
| PSV | |
| SPONT/CPAP | spont |
| A/C | s |
| SIGH | s |
| SIMV | s |
| MANUAL | s |
| APRV | |
| NON-INVASIVE(S, T, S/T) | |
| BIPAP | |
| Inspiratory trigger sensitivity | |
| Pressure | |
| Flow | |
| Sigh times | 1-5(every 100 times) |
| Oxygen concentration | 48%-100% |
| Pressure relief valve | |
| Ventilation parameters | |
| Tidal volume | s |
| Ventilation volume | s |
| Breathing rate | s |
| Inspiratory Duration | |
| Airway pressure | s |
| PEEP | |
| Oxygen concentration | |
| Control pressure | |
| Support pressure | |
| Waveform Display | |
| Pressure-time | s |
| Flow-time | |
| Pressure-volume Loop | |
| Alams | |
| Apnea | s |
| Vt too high(low) | s |
| Airway Pressure too high | s |
| F1O2 too high(low) | |
| O2 or Air supply failed | s |
| AC power failure | s |
| Battery under voltage | s |
| No tidal Volume | s |
