Features:
Perfect Image chain achieves sharp images.
The high quality image intensifier limprove the digital image quality.
XRME210101001
XINDRAY
Features:
Perfect Image chain achieves sharp images.
The high quality image intensifier limprove the digital image quality.
State of the art CCD camera with advanced noise reduction algorithms, are the key to consist image quality in every application.
The use of low absorption material and the grid packing capability, allow a consistent dose reduction.
New design and excellent movement control system
CCU(central control unit) realize the multi-grade denoise, various stroage, LIH, negative and positive, image reverse of the image.
The wide scanning range provides complete patient coverage without the need for longitudinal movement, result in faster positioning and better patient comfort.
The one-hand cassette loading and unloading mechanism grants a maximized speed for this frequent operation.
Product Configuration:
Remote Control console 1 set
Medical monitor 1 set
Remote diagnostic table 1 set
X-ray generator 1 set
X-ray tube assembly 1 set
High voltage cable 1 set
Electrical multi-leaf collimator 1 set
Image intensifier 1 set
Digital Workstation(optional) 1 set
CCD camera 1 set
Bucky stand(optional) 1 set
Technical Parameters:
Power output | 40KW | |
Tube focus | Large focus: 2.0 Small focus: 1.0 | |
Voltage | 380V±38V | |
Frequency | 50Hz±1Hz | |
Radiography | Tube Voltage | 44KV~125KV |
Tube Current | 32mA~500mA | |
Exposure time | 0.02s-4s | |
Fluoroscopy | Tube Voltage | 44KV~110KV |
Tube Current | 0.5mA~5mA | |
Foot stand | ±360° rotate foot stand | |
SID | 1100mm, 1500mm |
