1.Automatic probe cleaning, liquid level detection, collision protection
2.24 hour non-stop working,convenient emergency function with inserting emergency samples at random.
3.Discrete cuvette, preventing from crossinfection, and be washed and reused, making sure accurate result and save cost.
4.Perfect function of quality control management, convenient to manage the clinical test result.
5.Detecting in the whole reaction process with reaction curve, convenient for users to
monitor thoroughly and scientifically analyze the detection data.
XRME210302114
XINDRAY
Feature:
1.Automatic probe cleaning, liquid level detection, collision protection
2.24 hour non-stop working,convenient emergency function with inserting emergency samples at random.
3.Discrete cuvette, preventing from crossinfection, and be washed and reused, making sure accurate result and save cost.
4.Perfect function of quality control management, convenient to manage the clinical test result.
5.Detecting in the whole reaction process with reaction curve, convenient for users to
monitor thoroughly and scientifically analyze the detection data.
Technical Specification:
| Assay model | Random access with direct reading system | |
Assay Item | 80 assays | |
ISE mold (Na+ , K+ , Cl- /Li+) available on request | ||
Throughput | 1 Reagent | 400 tests/h(max) |
2 Reagent | 400 tests/h | |
With ISE | +120 tests/h | |
Sample position | 80 | |
Including standard, control and stat; either serum cup or primary tube available | ||
Sample Volume | 1~100ul, 0.1ul/step | |
Reagent Position | 2*40 | |
Reagent Volume | R1:1~400ul, 1ul/step, R2: 1~400ul, 1ul/step | |
Reaction Time | 0~999 seconds | |
Calibration | Liner, Non-liner, Multi standard, K factor | |
Wavelength | 340~810nm | |
Light Source | Halogen lamp | |
Absorbance Resolution | 0.0001A | |
Absorbance Accuracy | ±0.0003A(0~2.5A) | |
Repeatability (CV%) | ≤2% | |
Power Supply | 220V/50Hz or 110V/60Hz (optional) | |
Dimension | 100*85*70(cm) | |
Weight | 137kg | |
Feature:
1.Automatic probe cleaning, liquid level detection, collision protection
2.24 hour non-stop working,convenient emergency function with inserting emergency samples at random.
3.Discrete cuvette, preventing from crossinfection, and be washed and reused, making sure accurate result and save cost.
4.Perfect function of quality control management, convenient to manage the clinical test result.
5.Detecting in the whole reaction process with reaction curve, convenient for users to
monitor thoroughly and scientifically analyze the detection data.
Technical Specification:
| Assay model | Random access with direct reading system | |
Assay Item | 80 assays | |
ISE mold (Na+ , K+ , Cl- /Li+) available on request | ||
Throughput | 1 Reagent | 400 tests/h(max) |
2 Reagent | 400 tests/h | |
With ISE | +120 tests/h | |
Sample position | 80 | |
Including standard, control and stat; either serum cup or primary tube available | ||
Sample Volume | 1~100ul, 0.1ul/step | |
Reagent Position | 2*40 | |
Reagent Volume | R1:1~400ul, 1ul/step, R2: 1~400ul, 1ul/step | |
Reaction Time | 0~999 seconds | |
Calibration | Liner, Non-liner, Multi standard, K factor | |
Wavelength | 340~810nm | |
Light Source | Halogen lamp | |
Absorbance Resolution | 0.0001A | |
Absorbance Accuracy | ±0.0003A(0~2.5A) | |
Repeatability (CV%) | ≤2% | |
Power Supply | 220V/50Hz or 110V/60Hz (optional) | |
Dimension | 100*85*70(cm) | |
Weight | 137kg | |
