XRME2022040308
XINDRAY
Features:
Random access, fully automated, STAT
Constant 240T/H, up to 300T/H
60 reagent positions and 60 sample positions
81 reaction positions
Auto washing station
Optionals:
Sample barcode scanner
Specifications:
| Throughput | Constant 240T/H, up to 300T/H |
| Reagent tray | 60 reagent positions |
| Sample tray | 60 sample positions |
| Reaction cuvette | 81 resusable cuvettes |
| Wavelength | 8 wavelengths:340nm,405nm,450nm,510nm,546nm, 578nm,630nm,670nm |
| Dimension | 880mm (W) x650mm (D) x570mm (H) |
| Weight | 90kg |
| Power supply | AC 100~240V, 50/60Hz, ≤ 450VA |
| Packing size | 103.8*72.8*82.5cm |
| GW | 136kg |
Advantages:
Sampling system
One probe and one mixer bar
Auto depth adjustment
Liquid level detection
Collision protection
Sample & reagent disk
24-hour reagent refrigeration
60 reagent positions
60 sample positions with STAT priority
Reaction system
81 reaction cuvettes
Constant solid heating
Reaction temperature 37±0.1ºC
Minimum reaction volume 150 μl
Auto washing station
Real-time monitoring
Reagent inventory monitoring
Realtime water blank test
Realtime dirty cuvette detection
