XRME20220301023
XINDRAY
Features:
Excellent temperature control performance
High quality semiconductor thermoelectric module, combined with German high-end PT1000 temperature sensor and edge thermal compensation temperature.
Super multi-purpose function
Peltier Base heating module with multi-point temperature control can provide gradient temperature function of optimization experiment.
Extraordinary optical design
Maintance-free LED excitation light source, fluorescence signal of high temperature resistant professional fiber real-time transmission of 48-hole, high signal-to-noise ratio photodiode reading signal, ensure no edge effect.
Friendly, intuitive software setup interface
Quick response parameter setting wizard, intuitive sample setting wizard,powerful experimental data analysis function.
Fast lab start and report output
It does not need preheating and is easy to operate on and off and can be used for experiments in 30s. Intelligent data analysis,report output can be completed within 10 minutes.
Specifications:
| Basic performance | |
| Overall dimensions | 466*310*273mm |
| Weight | 18Kg |
| Power supply | 110V～240V,50～60Hz |
| Communication interface | USB |
| PCR system performance | |
| Tube capacity | 48*0.2ml |
| Sample volume | 20～120ul |
| Apply consumables | 0.2ml PCR tube、8*0.2ml PCR tube |
| Temperature control range | 4～99℃ |
| Temperature accuracy | ≤0.1℃ |
| Temperature uniformity | ≤±0.25℃ |
| Heating rate | 4.5℃/s |
| Cooling rate | 3.0℃/s |
| Heating/cooling | Semiconductor mode |
| Hot cover | Electric heat cover |
| Fluorescence detection system performance | |
| Light source | High brightness LED |
| Detector | PD |
| Excitation and detection of propagation media | High temperature resistant professional fiber |
| Linear range of samples | 100-109copies |
| Sample linearity | R≥0.99 |
| Sample testing repeatability | CV<1.00% |
