Multiple functions, compact design, easy to take, designed for transport and first aid. The main parts adopt good-quality components, which are accurate and reliable. LCD screen, simple and intuitive operation. Three kinds of power sources: AC, DC and internal battery.
XRME220204428
XINDRAY
Feature:
Multiple functions, compact design, easy to take, designed for transport and first aid. The main parts adopt good-quality components, which are accurate and reliable. LCD screen, simple and intuitive operation. Three kinds of power sources: AC, DC and internal battery.
Specification:
| Model | XRME220204379 | |||
| Modes | CMV, A/C, SIMV, SPONT | |||
| Tidal Volume | 50~1200ml | |||
| Respiratory Rate | 5~60bpm,1-12 bpm for SIMV | |||
| FiO2 | 40%~100% | |||
| Trigger | -10~0hPa | |||
| Max Minute Volume | ≥22L/min | |||
| PEEP | 0, 5 ~20hPa | |||
| PIP | 0~60hPa | |||
| Over Pressure Relief | ≤ 72hPa | |||
| Sigh | 0~10 per 100 breath | |||
| Base Flow | 0~5 L/min | |||
| Package Dimension | 520*520*270mm | |||
| Weight | 11kg(Including all the accessories) | |||
| Monitored Parameters: | Tidal Volume Sigh Respiratory Rate Peak Airway Pressure Trigger Airway Pressure Airway Pressure Wave Form | Alarms: | High Airway Pressure Alarm Low Airway Pressure Alarm High respiratory rate alarm Low Battery Alarm | |
Feature:
Multiple functions, compact design, easy to take, designed for transport and first aid. The main parts adopt good-quality components, which are accurate and reliable. LCD screen, simple and intuitive operation. Three kinds of power sources: AC, DC and internal battery.
Specification:
| Model | XRME220204379 | |||
| Modes | CMV, A/C, SIMV, SPONT | |||
| Tidal Volume | 50~1200ml | |||
| Respiratory Rate | 5~60bpm,1-12 bpm for SIMV | |||
| FiO2 | 40%~100% | |||
| Trigger | -10~0hPa | |||
| Max Minute Volume | ≥22L/min | |||
| PEEP | 0, 5 ~20hPa | |||
| PIP | 0~60hPa | |||
| Over Pressure Relief | ≤ 72hPa | |||
| Sigh | 0~10 per 100 breath | |||
| Base Flow | 0~5 L/min | |||
| Package Dimension | 520*520*270mm | |||
| Weight | 11kg(Including all the accessories) | |||
| Monitored Parameters: | Tidal Volume Sigh Respiratory Rate Peak Airway Pressure Trigger Airway Pressure Airway Pressure Wave Form | Alarms: | High Airway Pressure Alarm Low Airway Pressure Alarm High respiratory rate alarm Low Battery Alarm | |
