It adopts light sources from different positions for focus to eliminate shadows of different parts of medical workers. Vertical mobile setup with braking device is not limited by the space of surgical room and is safe and reliable in use.
 |
It adopts light sources from different positions for focus to eliminate shadows of different parts of medical workers. Vertical mobile setup with braking device is not limited by the space of surgical room and is safe and reliable in use.
XRME220201403
XINDRAY
Feature:
It adopts light sources from different positions for focus to eliminate shadows of different parts of medical workers. Vertical mobile setup with braking device is not limited by the space of surgical room and is safe and reliable in use.
Specification:
Illumination (lux) :100000
Color Temperature (K) : 4000±500
Color rendering index:100≥Ra≥85
Depth of light beam (mm) :≥500
The value of the total irradiance(service range for temperature rise≤10℃) :<6mW/m2lx
Total irradiance(Temperature rise on the head of patient under surgical operation≤2℃): ≤600W/m2
Power supply(AC):220V±10% 50Hz DC24V
Rated voltage of bulb:24V
Rated power of bulb :125W
Input power(VA) :150
G. W:60KG
Package dimension: 970*670*740
Packaging material:Carton
Feature:
It adopts light sources from different positions for focus to eliminate shadows of different parts of medical workers. Vertical mobile setup with braking device is not limited by the space of surgical room and is safe and reliable in use.
Specification:
Illumination (lux) :100000
Color Temperature (K) : 4000±500
Color rendering index:100≥Ra≥85
Depth of light beam (mm) :≥500
The value of the total irradiance(service range for temperature rise≤10℃) :<6mW/m2lx
Total irradiance(Temperature rise on the head of patient under surgical operation≤2℃): ≤600W/m2
Power supply(AC):220V±10% 50Hz DC24V
Rated voltage of bulb:24V
Rated power of bulb :125W
Input power(VA) :150
G. W:60KG
Package dimension: 970*670*740
Packaging material:Carton
